Model PV450 Rated Maximum Power(Pm) 450W Measurement Tolerance - 3% Power Sorting 0- 5W Voltage at Pmax(Vmp) 41.33V Current at Pmax(lmp) 10.89A Open-Circuit Voltage(Voc) 49.70 x(1 3%)V Short-Circuit Current(lsc) 11.41*(1 4%)A Maximum System Voltage 1500VDC Maximum Series Fuse Rating 20A Operating Temperature 40 C to 85 ‘C Cell Technology Mono-Si Designed Load(Front/back) 3600/1600Pa Mechanical Load Safety Factor 1.5 All technical data at standard test condition, AM=1.5 E=1000WIm? TC=25°C
